| Models | 3K | 3.6K | 5K | 6K | 8K | 10K(21A) |
| Input DC (PV side) | ||||||
| Recommended max. PV array size | 6 kW | 7.2 kW | 10 kW | 12 kW | 16 kW | 20 kW |
| Max. usable PV input power | 4.8 kW | 5.76 kW | 8 kW | 9.6 kW | 12.8 kW | 16 kW |
| Max. input voltage | 500 V | 500 V | 500 V | 500 V | 500 V | 500 V |
| Rated voltage | 330 V | 330 V | 330 V | 330 V | 330 V | 330 V |
| Start-up voltage | 90 V | 90 V | 90 V | 90 V | 90 V | 90 V |
| MPPT voltage range | 90 – 435 V | 90 – 435 V | 90 – 435 V | 90 – 435 V | 90 – 435 V | 90 – 435 V |
| Max. input current | 16 A / 16 A | 16 A / 16 A | 16 A / 16 A | 16 A / 16 A | 32 A / 32 A | 42 A / 42 A |
| Max. current per DC input | 16 A | 16 A | 16 A | 16 A | 16 A | 21 A |
| Max. short circuit current | 20 A / 20 A | 20 A / 20 A | 20 A / 20 A | 20 A / 20 A | 40 A / 40 A | 48 A / 48 A |
| MPPT number / Max. input strings number | 02-Feb | 02-Feb | 02-Feb | 02-Feb | 02-Feb | 04-Feb |
| Battery | ||||||
| Battery type | Li-Ion / Lead-acid | Li-Ion / Lead-acid | Li-Ion / Lead-acid | Li-Ion / Lead-acid | Li-Ion / Lead-acid | Li-Ion / Lead-acid |
| Battery voltage range | 40 – 60 V | 40 – 60 V | 40 – 60 V | 40 – 60 V | 40 – 60 V | 40 – 60 V |
| Max. charge / discharge power | 3 kW | 3.6 kW | 5 kW | 6 kW | 8 kW | 10 kW |
| Max. charge / discharge current | 70 A | 80 A | 112 A | 135 A | 190 A | 210 A |
| Number of battery port / number of BMS port | 01-Jan | 01-Jan | 01-Jan | 01-Jan | 01-Jan | 01-Jan |
| Communication | CAN / RS485 | CAN / RS485 | CAN / RS485 | CAN / RS485 | CAN / RS485 | CAN / RS485 |
| Output AC (Grid side) | ||||||
| Rated output power | 3 kW | 3.6 kW | 5 kW | 6 kW | 8 kW | 10 kW |
| Max. apparent output power | 3 kVA | 3.6 kVA | 5 kVA | 6 kVA | 8 kVA | 10 kVA |
| Rated grid voltage | L/N/PE, 220 V / 230 V | L/N/PE, 220 V / 230 V | L/N/PE, 220 V / 230 V | L/N/PE, 220 V / 230 V | L/N/PE, 220 V / 230 V | L/N/PE, 220 V / 230 V |
| Rated grid frequency | 50 Hz / 60 Hz | 50 Hz / 60 Hz | 50 Hz / 60 Hz | 50 Hz / 60 Hz | 50 Hz / 60 Hz | 50 Hz / 60 Hz |
| Rated grid output current | 13.7 A / 13.1 A | 16.4 A / 15.7 A | 22.8 A / 21.8 A | 27.3 A / 26.1 A | 36.4 A / 34.8 A | 45.5 A / 43.5 A |
| Power factor | > 0.99 (0.8 leading – 0.8 lagging) | > 0.99 (0.8 leading – 0.8 lagging) | > 0.99 (0.8 leading – 0.8 lagging) | > 0.99 (0.8 leading – 0.8 lagging) | > 0.99 (0.8 leading – 0.8 lagging) | > 0.99 (0.8 leading – 0.8 lagging) |
| THDi | < 3% | < 3% | < 3% | < 3% | < 3% | < 3% |
Supports PV input up to 160% of the inverter’s rated DC power, maximising solar utilisation
• Supports up to 21A PV input current, compatible with future higher-power PV modules
• 200% overload for 10s in off-grid mode, ensuring stable startup of motors, water pumps and air conditioners
• Seamless on/off-grid switching in under 10ms, guaranteeing an uninterrupted power supply
• More battery options, compatible with any battery (between 40V-60V)
• Supports existing PV grid-tied power connection for export control and off-grid use
• Multiple methods of generator connection and auto control, enabling flexible local deployment
• Support max 6 units in parallel, expanding system capacity
• Smart Load management, extending backup time for critical loads
• Customizable battery backup level for uninterrupted power
• Supports PV-only off-grid operation, reducing upfront costs
• AI-Powered & VPP-Ready – maximise savings, unlock additional income
• 7-inch industrial-grade LCD screen, providing a larger, user-friendly interface for local operation
• Ingress protection IP66, for operation in harsh conditions
